Developed by Anchor Yachts

Designed by Schionning Designs

Built by Pacific Seacraft in the USA

Different by Design

  • Inside helm station with full sail controls and excellent sight lines
  • Carbon mast and V-boom with Bamar electric furler for the square top mainsail, combined with self tacking jib boom makes for simple enjoyable sailing
  • Skeg with foil provides propeller protection and improves sailing performance
  • Kick up rudders to allow for shallow water (2′) operation under power, and allow the boat to rest on the protective skeg when beached
  • Large tankage – 210 gallons of fuel, 105 gallons of water
  • Weighing less than 20,000 lbs (with full tanks) makes for a truly light performance cruising catamaran, which is easily driven with routine cruising speeds of 15 knots+ and capable of 25+ knots
  • Hull, deck, and structural bulkheads are built with foam cores utilizing carbon fiber and kevlar layers in high load areas to achieve optimum strength with minimum weight

Razor Cat 52 – Overview

The focus of this design is elegant performance. An offshore capable multihull which is easily controlled and operated by one person from the safety and comfort of a central inside helm station, featuring 360 degree views throughout the bridge deck. All lines (with the exception of the genoa/spinnaker sheets) lead to two electric reversible winches located either side of the helm. The genoa/ spinnaker sheets are handled by the two electric reversible winches in the cockpit (that can also be controlled remotely at the helm). Couples that have spent time cruising know how critical it is to be able to handle the boat easily while on watch without having to wake your partner, this is not possible on most catamaran designs.

A properly designed and constructed catamaran can be a very fast, but only if it remains light and easily driven. This design has relatively narrow hulls with dagger boards, along with simple powerful rig. The high bridge deck clearance minimizes pounding in a seaway and greatly adds to the comfortable motion aboard while sailing. All systems are designed to be easily accessed and maintained, a critical feature on any true cruising sailboat.

The bridge deck offers indoor/outdoor living at its finest, with excellent sight lines when sitting or standing, in the salon as well as on the aft deck. While the inside helm is the control center of the boat, the large U-shaped galley is the heart of the boat and is located on the bridge deck across from the dinette with easy access to the aft deck. The galley features a bar, under counter fridge/freezer drawers, a large sink, a proper stove with oven, along with substantial counter space and storage.

The accommodations in each hull are configured to provide a generous aft cabin with a queen berth that is easy to get into from the foot of the berth, along with ample storage. Moving forward is a modified queen midship berth (which folds up to reveal a work bench when needed). Next is a large forward head compartment with separate shower stall and large hanging locker. On the occasion you have additional guests the dinette also converts to a spacious double berth.

The market has seen an ever increasing demand for catamarans, particularly among sailors who have previously owned cruising monohulls. These buyers are looking for a catamaran that is well built offering: speed, comfort, and safety that is easy to handle while remaining a joy to sail. They also want a design that allows them to enjoy indoor/outdoor living (while underway and at anchor) in a way that is not possible on a traditional monohull. However, most catamarans on the market are designed and built for the charter market, which focuses on maximizing the number of berths and interior accommodations without concern of the adverse effects it has on sailing performance. The Razor Cat focuses on what experienced sailors are looking for in a performance cruising catamaran.

Razor Cat 52 – Specifications

  • LOA – 52 ft
  • BOA – 26’ 4”
  • Ratio beam/length – 13.7:1
  • Draft (boards up) – 2′
  • Draft (boards down) – 6’2”
  • Bridgedeck clearance – 3′
  • Full Displacement – 19,730 lbs (full tanks)
  • Lightship Displacement – 17,000 lbs (empty tanks)
  • Payload – 5,732 lbs
  • Engines – 2 x 45 hp Yanmar diesels with straight shafts, or optional OceanVolt hybrid system
  • Tankage – 105 gal. water, 210 gal. fuel
  • Headroom – 6’9”
  • Mast clearance – 64’
  • Jib sail area – 419 square feet
  • Mainsail area – 861 square feet
  • 6 degree mast rake, square top mainsail

RAZOR CAT - PERFORMANCE OFFSHORE CRUISING CATAMARAN

josh

Origins of the Razor Cat

The development of the Razor Cat is the result of my personal experiences cruising with my wife  aboard our performance offshore catamaran, as well as my 15+ years selling new and used yachts. During that time I have been listening to what my clients have been searching for in a cruising catamaran, and the Razor Cat is the culmination of those experiences.

I am excited to be working with such a talented team to bring the Razor Cat to life:

Schionning Designs has been designing performance multihulls for over 25 years. Credited with over 400 boats on the water and cruising the world and zero failures on record, speaks to the success of their designs.

Pacific Seacraft has earned a reputation as a highly skilled builder of ocean going yachts, which they build with pride in Washington, NC USA. Their passion for boat building will be evident from your initial contact, throughout the entire build process, and after you take delivery of your new Razor Cat.

I am confident that the Razor Cat’s combination of innovative design, easily controlled sailing performance, and exceptional build quality, will bring joy to her owners and all aboard.

Elevate your sailing experience with the Razor Cat 52.

Josh Hodgson –  Owner of Anchor Yachts and Principal of Razor Cat

Razor Cat 52 Layout Drawings

Click on image to enlarge



Razor Cat 52 – Features

  1. Built using carbon fiber and Kevlar in the high stress areas to ensure the optimum strength while keeping the weight down
  2. Layout designed with single inside helm station, and removable tillers for outdoor steering when desired
  3. Large sliding hatch over inside helm to allow for easy sail inspection and ventilation
  4. Harken 60 electric self-tailing Rewind Radial primary winches mounted either side of the helm with clutches for the following lines:
    – Halyards (Mainsail, Jib, Genoa, Spinnaker)
    – Furling lines (Mainsail, Jib, Genoa)
    – Jib Sheet, jib outhaul, jib boom topping lift
    – Mainsheet
    – Main boom topping lift
  5. Harken 60 electric self-tailing Rewind Radial Genoa winches on the aft coaming in the cockpit with controls at helm as well
  6. Manual Antal Line driver for raising and lower dagger boards at helm
  7. Power electric line driver for mainsail traveler, controls at helm as well as each aft winch. Traveler can also be controlled by aft winches if needed as a manual back up.
  8. Large U-shaped gourmet galley with cockpit bar: featuring two Virtifrigo under counter drawer refrigerator/ freezer, induction stove with oven, as well as substantial storage space with a pantry and additional counter space forward of the galley
  9. Cockpit has a full hard top, a bar, along with a grill and beverage fridge built in to the aft coaming
  10. Large flush solar panel array on top of salon/ cockpit
  11. Each hull features aft cabin with queen berth abundant storage, a modified queen midship berth orientated fore and aft that converts to to a work bench when needed, with a head and large separate shower forward
  12. Dometic Turbo 16,000 BTU reverse cycle air conditioning/heating in each hull
  13. Vacuflush electric toilets in each hull
  14. Electronics package: owners choice (such as B&G, Garmin, or Raymarine)
  15. Jefa transmission steering system with carbon rudders, and carbon wheel
  16. Protective skeg with foil forward of the outdrives that protects the props and provides lift for the vessel, as well as safe beaching with kick up rudder system
  17. Jib on Bamar GFM roller furler
  18. Self-tacking carbon jib boom for jib
  19. Genoa/code zero on Bamar RLG EVOS roller furler
  20. Square topped mainsail
  21. Option: Aluminum rig
  22. Option: Non furling boom with lazy jacks and slab reefing
  23. Option: OceanVolt electric propulsion system (in lieu of twin 45 hp Yanmar diesel engines)
    – 2 x SD15 electric motors with Servoprop
    – 2 x 7 KW hydro regeneration system
    – 2 x 12 KW Whisper Power 48V DC generator
    – Valence 10.5KWh lithium battery bank
  24. Option: Espar D5LC diesel force air cabin heaters in each hull
  25. Option: Spectra Cape Horn Extreme watermaker
  26. Option: Offshore Cruising Tenders 350 carbon fiber tender

The Razor Cat Team

Anchor Yachts

Anchor Yachts was established in 1998. Providing international yacht brokerage services, as well as authorized representation for new Outbound Yachts, Pacific Seacraft, Surfari, Razor Cats, Zeelander Yachts, and Sterling Yachts. Our experience saves our clients time, money, and mistakes when purchasing and selling their yachts.

Josh Hodgson is the proud owner of Anchor Yachts. His love of boats started early in life while living aboard a catamaran in the Virgin Islands with his family when he was young. Boats have always been a presence and a passion in his life. He even met his wife while water skiing!

Applying his own sailing experiences, from living aboard a sailboat, to offshore voyages and coastal deliveries aboard a variety of boats, he has gained a firsthand appreciation of what makes a boat ready for sea. In addition, as the owner of Anchor Yachts since 2004, Josh has gained valuable experience by working with boaters to determine what they need in a boat to best accomplish what they are looking to do on the water.

Josh has listened to the comments and concerns of hundreds of boaters and have learned what it is that both men and women want in a proper boat. Through his long standing relationships with previous clients, he has come to know what they love about their boats and what they would like to change.

Josh is proud to have a long track record of helping people get what they want and maintaining positive relationships with his clients long after the sale. He looks forward to helping you expand your horizons on the water.

Pacific Seacraft

Pacific Seacraft was conceived more than 40 years ago in Southern California and has over the years become the preeminent builder of heavy weather capable bluewater sailing vessels.  Astonishingly, each model boat in the line has circumnavigated, with the venerable PS-34, 37, 40, and 44’s continuing to do it with regularity.

In 2007 Pacific Seacraft came under new ownership and was relocated to North Carolina.  Many of the longtime key personnel and department heads made the move to North Carolina and continue there today.  This new era saw an even further evolution of the commitment to robust construction, real world ocean performance, and aesthetic beauty.

Pacific Seacraft has continued to build the Crealock line which remains a very relevant and viable cruising sailboat series.  With Steve Brodie at the helm, the company began to expand their talent base and pursue larger custom and semi-custom projects.  These included the SouthSea 61 designed by Robert Perry, which is available in a dual cockpit ketch and deck salon sloop configurations.  This vessel is a model of modern technical construction with very traditional finishes.  She is billed as a gentleman’s world cruiser whose beauty is only exceeded by her capability.

Working in conjunction with designer Ted Fontaine, Pacific Seacraft built the very unique, and very high tech, Surfari 50 performance sloop for entertainer Jimmy Buffett.  Surfari boasts a lightweight infused epoxy hull with carbon reinforcing structure, carbon chain plates, hydraulic and electric controls for everything from mainsheet to transom tailgate, a pushbutton hydraulic lifting keel in a carbon fiber trunk, etc. All of this was executed with an of exceptional level of craftsmanship throughout, including unmatched interior woodwork details.

On the other end of the spectrum (and indicative of the company’s range), Pacific Seacraft is currently performing a full restoration of the last remaining North Carolina built Skipjack, built in 1915, and a very important part of North Carolinas maritime heritage.

While remaining true to the companies roots by continuing to produce very strong, beautiful, uncompromising vessels; Pacific Seacraft is also embracing new technologies, materials, and processes to continue to evolve and improve performance at sea.  This includes epoxy sandwich infusion construction, employment of high strength aramid and carbon fiber laminates, titanium fabrications, advanced hydraulics, etc.

An uncompromising high quality standard is maintained by performing the work in-house and in the USA.  Additionally, all materials and components undergo a rigorous evaluation with American and European components being employed where possible. While having evolved into more of a semi-custom builder, Pacific Seacraft has maintained and developed a broad range of in-house artisans and capabilities ranging from high tech composite fabrications, to metal fabrication and machining, to exquisite upholstery.  The Pacific Seacraft team boasts over 200 years of combined boatbuilding experience.  This level of experience, range, and control not only ensures a very high standard of quality but also to allow advanced levels of customization and engagement for discerning clients.

Schionning Designs

Schionning Designs has been working within the marine industry, in Australia and around the World, to engineer and develop luxury cruising and racing multihulls using the best composite solutions. Having designed catamarans for more than 25 years, Schionning Designs has grown to become one of the World’s top multihull designers.

Schionning Designs are some of the safest, fastest, most luxurious cruising catamarans on the market today. With over 400 boats on the water, cruising the worlds oceans, and zero design failures on record, the designs have proven themselves in the real world.

Contact for more information

401-246-2100
